ME3951A gigahertz Solutions for €580 incl. VAT + pole + case + free shipping
(Prices incl. VAT, except outside the EU)
ME3951A device for measuring and detecting electric and magnetic fields for professionals. Analysis of a frequency band from 5 Hertz to 400,000 Hertz (400 KHz) with a frequency filter that separates the frequency bands.
The ME3951A has the "common advantages". It is particularly popular among doctors and naturopaths, as it ideally combines simple operation with professional measurements. It allows for simple allocation of electrostress frequencies to traction current, line current, or even artificial harmonics, thus facilitating a particularly accurate consultation of possible remediation measures and simple monitoring of their effectiveness. It has four frequency band filters and an audio output for connection to a spectrum analyser.
It includes all the features of the ME3951A and offers the following additional features:
- Four internal switchable filters, as on professional devices, allow analysis of different frequency bands, such as those produced by railway traction current and those produced by artificial sources of higher frequencies, from 5 Hz to 400 kHz, 16 Hz for railway current 50 Hz to 400 kHz for mains current and harmonic waves, 2 kHz to 400 kHz artificial harmonic waves
- Broadband measurement (RMS)
- Limit values are lower for higher frequencies.
- Electric field probe relative to ground potential, one-dimensional magnetic field
- AC and DC outputs
| Frequency band: | 5 Hz to 400 KHz (compensated, better than -2 dB). Internal and adjustable frequency filter: 16.6 Hz bandpass filter, 50 Hz high-pass filter, 2 kHz high-pass filter for identification and evaluation of pollution sources |
| Measuring range: | Magnetic flux density (one-dimensional): 0.1 - 1999 nT Electric field strength: 0.1 - 1999 V/m |
| Accuracy: | +/- 2%, +/- 7 digits @ 50/60 Hz |
| Sensor: | E probe for measuring LF electric fields - B probe for measuring LF magnetic flux density |
| Audio analysis: | An acoustic signal proportional to the field strength, similar to a "Geiger counter effect", helps to identify areas of high exposure. |
| Power supply: | Rechargeable battery included in the instrument Average operating time of 7 to 8 hours "Low-Batt." energy level indicator on the screen, automatic power-off function ("Auto-power-off") Charger/power supply included |
| Signal evaluation: | RMS |
| Outputs: | AC and DC output |
| Several questions: | 2-year warranty |
| Weight: | 0.74 kg |
Contents of the box:
- Analyser
- Grounding cable
- Charger
- Integrated NiMH battery with charge control
- Various adapters
- Detailed user manual with field theory.
- Pole
- Carrying case
-
ConditionNew
