HFW59b Gigahertz Solutions + free shipping

€915.00

(Prices incl. VAT, except outside the EU)

The HFW59b measures frequencies from 2.4 GHz to 10 GHz, including Wi-Fi (2.4 and 5.1 GHz), Wi-Max, radar, WLANs, 4G/LTE and the future 5G.

It measures frequencies from 2.4 GHz to 10 GHz, including Wi-Fi (2.4 and 5.1 GHz), Wi-Max, radar, WLANs, 4G/LTE, and 5G (3.49 and 3.8).

For measuring frequencies between 2.4 and 10 GHz
A very special measuring instrument that can measure radiation from wireless technologies or wireless computer networks, including standards such as Bluetooth, WLAN, Wi-Fi and radar. It also covers the frequencies of WiMAX transmitters in operation since 2006.
It comes with a specially shaped log-per antenna with excellent directionality (patent: AZ 10 2006 051 180.8).
A special filter that suppresses DECT and mobile phone frequencies is integrated into the device so as not to alter the measurement of frequencies between 2.4 and 6 GHz.
Equipped with a professional device switch for quantitative differentiation between pulsed and non-pulsed radiation.

Frequency range:	2.4 - 10.0 GHz
Measuring range:	Power density: 1 - 1999 uW/m²
Accuracy:	Basic accuracy and linear tolerance: +/- 4.5dB
Sensor:	Optimised logarithmic periodic antenna with antenna compensation and improved directional reception
Audio analysis:	Identification of the nature of pulsed radiation sources (mobile phones (GSM, UMTS/G3), cordless phones (DECT), WLAN (Bluetooth), air traffic control radars, etc.) by means of an acoustic signal proportional to the modulated frequency.
Power supply:	9-volt alkaline manganese battery Average operating time of 6-8 hours Low battery indicator on screen, automatic power-off function
Signal evaluation:	Display of peak values and average values (AVG) (switchable) Quantitative differentiation between pulsed and non-pulsed radiation.
Weight:	0.45 kg

Contents of the box:

Measuring device Logarithmic antenna and connection cable Alkaline manganese battery Detailed operating instructions
