Cornet ED88TPlus5G2 5G-compatible for €188 including VAT

Cornet ED88TPlus5G2: High-frequency and low-frequency electric and magnetic field detector (100 MHz to 8 GHz) and (50 to 50 kHz).

The new model differs from its predecessor, the CORNET ED88T Plus2, in that it offers the following additional features:

• 5G frequency compatibility
• 5G measurement in the 3.5 GHz band
• A data recording display mode that allows you to view the RF mode values recorded on SRAM (buffer memory) before deciding whether or not to save them to the FLASH data recording memory.

• A replay of the values read in RF mode and recorded in the FLASH memory.

• A real-time value recording mode for measuring electric and magnetic fields, which can be transferred to a computer via a USB cable.
• A function for viewing high-frequency digital values taken in bursts.
• Data recording on a PC via the Cornet Logger / Data Logger software, which can be downloaded from the Cornet Microsystem website http://electrosmog.org/, via a USB cable (not supplied) connected to the CORNET ED88Tplus5G2.
• Displays the frequency of the main source measured (up to 4.2 GHz).

It measures:

• high-frequency electromagnetic fields in a band from 100 MHz to 8 GHz, i.e. 5G wave measurement with display of the main frequency measured in the frequency band from 100 MHz to 2.7 GHz, and with audio demodulation via loudspeaker or headphone jack. Volume control and also Wi-Fi, relay antenna, 2/3/4/5G, DECT, TETRA, Wimax, Bluetooth, connected objects, radar, etc.;
• low-frequency magnetic fields.
• low-frequency electric fields (the first Cornet with this capability).

Technical specifications:

• Acoustic frequency detection function with volume control

• USB port for external power supply or data transfer to a PC

• A jack output for connecting headphones

High frequencies:

• Frequency range: 100 MHz to 8 GHz
• Boxes, terminals and antennas: WiFi, Wimax, WLAN (2.4 GHz – 3.5 GHz – 5.8 GHz and WiFi6 6-7 GHz).
• Bluetooth-connected devices and objects (2.4 to 2.48 GHz).
• DECT cordless phones (1880 to 1900 MHz).
• Mobile phones and relay antennas (2G, 3G, 4G, 700 to 2600 MHz,
• Tetra network (380-470 MHz)
• 5G mobile telephony (600 MHz to 6 GHz), 700 MHz and (3.46 to 3.9 GHz).
• Mobile phones and everyday connected devices, computers, tablets, game consoles.

• High sensitivity: -60 to +5 dBm (14 mV/m to 26.2 V/m, 0.5 µW/m² to 1.8 W/m²)

• Dynamic range: 65 dB

• Display of measured main frequency: from 100 MHz to 2.7 GHz (-35dBm minimum input signal required for this function to operate)

• 8 coloured LEDs for exposure assessment (New and highly appreciated on this new model in the Cornet range: adjustable sensitivity of this parameter to German habitat biology values!)

• Programmable audible alert in dBm, emitting beeps and the sound of the recognised main source

• High frequency measurement error rate: +/- 3.5 dBm.

Low-frequency magnetic field (2 measurement scales)

• LF600 mode: 50Hz to 10 kHz from 0.1 µT to 60 µT (1 mG to 600 mG).

• LF30 mode: 50 Hz to 1 KHz from 0.01 µT to 1 µT (0.1mG to 10 mG). Low frequency magnetic field measurement error rate: 20%, with Max function and measurement hold function

Low-frequency electric field:

• 50 Hz to 50 KHz (10 V/m to 1000 V/m). Low-frequency electric field measurement error rate: 25%.

Features:

• Backlit LED graphic LCD display and manual on/off switch Units of measurement: dBm, mW/m², µW/m², V/m, µT, mG, MHz

• Data update rate: Sampling rate: 10,000/sec. Display update rate: 2/sec.

• Functions in English: Mode, Hold, Light, Unit, Max, Average, Sound signature, Alarm, Frequency.
• Functions in French: Mode, Hold, Lighting, Units, Maximum, Average, Sound signature, Alarm, Frequency.
• English or French mode

• Sound & Alarm: Sound system control ON/OFF, Alarm programmable by power level.
• Measurement acquisition speed: 10,000 samples per second (10,000/sec).
• Display speed: 2 measurements per second.
• Software: downloadable (see user manual), compatible with Windows 7, Windows 95/98/ME, Windows NT/2000 and above.

• Standard safety indication: 3 safety level indications via 3 red/yellow/green LEDs, adjustable LED level
• Battery life: 20 hours

• Dimensions: 137x71x25mm
• Power supply: 9V alkaline battery or 9V Li-ion rechargeable battery

• Battery life: approximately 20 hours
• Equipment supplied: ED88T detector
