• HF38b Gigahertz - Detecteur Hautes Fréquences

HF38B Gigahertz Solutions at €440 including VAT

€366.67

(Prices incl. VAT, except outside the EU)

The Gigahertz Solutions HF38b measures frequencies from 800 MHz to 3.3 GHz (with optional additional tolerance at 3.3 GHz), i.e. GSM 900, DCS 1800, UMTS/3G mobile phone base stations, UMTS/3G, Tetra for the police, ambulances and emergency services, radio, DECT, WLAN, Wi-Fi, Wi-Max and radar.

The Gigahertz Solutions HF38b measures frequencies from 800 MHz to 3.3 GHz (with optional additional tolerance at 3.3 GHz), i.e. GSM 900, DCS 1800, UMTS/3G mobile phone base stations, UMTS/3G, Tetra for the police, ambulances and emergency services, radio, DECT, WLAN, Wi-Fi, Wi-Max, and radar.



Sound demodulation for frequency sound analysis. It is particularly popular among doctors and naturopaths, as it ideally combines simple use with professional measurements. It allows for easy allocation of electrostress frequencies to traction current, line current, or even artificial harmonics, thus facilitating a particularly accurate consultation of possible remediation measures and a simple check of their effectiveness.

 It has the same functions and configurations as the HF35C but with these additional professional features:

  • A Log-per antenna with improved frequency sensitivity.
  • 10 times greater sensitivity: minimum screen resolution of 0.01 µW/m² *
  • An extended measurement range improved by a factor of 10: max. 19.99 mW/m² *
  • Measurement is significantly simplified with the help of the "peak-hold" function*



Frequency range:

800 MHz - 2.5 GHz (with additional tolerance 3.3 GHz)

Measurement range:

Power density: 0.01 - 19.990 µW/m²

Accuracy:

Basic accuracy and linear tolerance: +/- 6dB Zero (offset)
and rollover verification: +/- 9 digits

Sensor:

Optimised logarithmic periodic antenna: ripple, directional reception, shielding to ground

Audio analysis:

Identification of the nature of pulsed radiation sources (mobile phones (GSM, UMTS/G3), cordless phones (DECT), WLAN (Bluetooth), air traffic control radars, etc.) by means of an acoustic signal proportional to the modulated frequency.

Power supply:

9-volt alkaline manganese battery
Average operating time of 6-7 hours Energy
level indicator on screen "Low Batt.", automatic power-off function ("Auto-power-off")

Signal evaluation:

Display of peak and peak hold values as well as average values (AVG) (switchable)

Several questions:

2-year warranty

Weight:

0.58 kg

 Contents of the box:

Measuring device Log-per. antenna and connection cable Alkaline manganese battery Detailed operating manual

  • Condition
    New
